JIT Toolchain: Building a Disassembler and CPU Emulator for Database Development

The essential infrastructure that makes Copy-and-Patch JIT development and debugging practical

In our previous post, we explored how Copy-and-Patch JIT compilation achieves native code performance with microsecond compilation times. But generating machine code is only half the battle. How do you debug a stencil that crashes? How do you verify that patched offsets land at the right instruction boundaries? How do you test JIT code on a development machine running a different CPU architecture?

This post dives into the JIT toolchain we built for Cognica Database Engine: a multi-architecture disassembler for validation and a software CPU emulator for cross-platform testing and debugging.

The Problem: JIT Development is Hard

JIT compilation introduces debugging challenges that traditional ahead-of-time compilation avoids:

1. Invisible Code: JIT-compiled code doesn't exist until runtime. You can't run it through a debugger before execution.

2. Patch Point Validation: Copy-and-Patch JIT relies on patching specific byte offsets. A patch that lands in the middle of an instruction causes crashes or silent corruption.

3. Cross-Platform Development: Developers on Apple Silicon need to test x86-64 stencils. Developers on x86-64 need to verify ARM64 code.

4. Performance Isolation: When a query runs slowly, is it the JIT code, the interpreter, or the query plan? Isolating JIT behavior requires controlled execution.

These challenges demand specialized tooling: a disassembler that understands our stencil format and an emulator that can execute stencils in isolation.

Architecture Overview

Our JIT toolchain consists of three main components that work together:

The disassemblers decode native machine code for validation and debugging output. The translators convert native code to an architecture-neutral intermediate representation (IR). The execution engine interprets the IR, enabling cross-platform execution and fine-grained debugging.

The Disassemblers: Understanding What We Generated

Why Not Use Existing Tools?

Tools like objdump, llvm-objdump, and Capstone are excellent for general-purpose disassembly. But our stencils have specific requirements:

1. Patch Validation: We need to verify that patch offsets align with instruction boundaries and target the correct immediate fields.

2. Minimal Footprint: Adding a 50MB LLVM dependency for disassembly is excessive when we only use ~110 instruction patterns.

3. Integration: We want disassembly as a first-class debugging feature, not an external tool invocation.

Our disassemblers support exactly the instruction subset used in stencils---nothing more, nothing less.

x86-64 Disassembler

x86-64's variable-length encoding makes disassembly challenging. An instruction can be 1-15 bytes, with complex prefix combinations:

// x86-64 disassembler structure
class X86_64Disassembler {
public:
  auto disassemble(const Stencil& s) const -> DisassemblyResult;
  auto validate_patches(const Stencil& s) const -> std::vector<std::string>;
  static auto format(const DisassembledInst& inst) -> std::string;

private:
  // REX prefix structure
  struct Rex {
    bool present;
    bool w;  // 64-bit operand size
    bool r;  // ModRM.reg extension
    bool x;  // SIB.index extension
    bool b;  // ModRM.rm extension
  };

  auto decode_one_(const uint8_t* code, size_t len, uint32_t offset) const
      -> DisassembledInst;
  static auto parse_rex_(uint8_t byte) -> Rex;
  auto decode_modrm_mem_(const uint8_t* code, size_t len, const Rex& rex,
                         bool is_64bit) const -> std::pair<std::string, size_t>;
};

The key complexity lies in the REX prefix and ModR/M byte parsing. A REX prefix (0x40-0x4F) extends register addressing to access r8-r15. The ModR/M byte encodes both the addressing mode and register operands:

auto X86_64Disassembler::parse_rex_(uint8_t byte) -> Rex {
  Rex rex;
  rex.present = (byte >= 0x40 && byte <= 0x4f);
  if (rex.present) {
    rex.w = (byte & 0x08) != 0;  // 64-bit operand
    rex.r = (byte & 0x04) != 0;  // Extends ModRM.reg
    rex.x = (byte & 0x02) != 0;  // Extends SIB.index
    rex.b = (byte & 0x01) != 0;  // Extends ModRM.rm
  }
  return rex;
}

ARM64 Disassembler

ARM64's fixed 32-bit instruction encoding is simpler to decode but has its own subtleties. All instructions are 4 bytes, and the instruction category is determined by fixed bit positions:

class AArch64Disassembler {
public:
  auto disassemble(const Stencil& s) const -> DisassemblyResult;
  auto validate_patches(const Stencil& s) const -> std::vector<std::string>;

private:
  auto decode_one_(uint32_t instr, uint32_t offset) const -> DisassembledInst;

  // Bit field extractors
  static auto rd(uint32_t i) -> uint8_t { return i & 0x1f; }
  static auto rn(uint32_t i) -> uint8_t { return (i >> 5) & 0x1f; }
  static auto rm(uint32_t i) -> uint8_t { return (i >> 16) & 0x1f; }
  static auto rt(uint32_t i) -> uint8_t { return i & 0x1f; }
  static auto rt2(uint32_t i) -> uint8_t { return (i >> 10) & 0x1f; }

  // Instruction decoders by category
  auto decode_dp_reg_(uint32_t instr) const -> DisassembledInst;
  auto decode_dp_imm_(uint32_t instr) const -> DisassembledInst;
  auto decode_fp_(uint32_t instr) const -> DisassembledInst;
  auto decode_ldst_(uint32_t instr) const -> DisassembledInst;
  auto decode_branch_(uint32_t instr) const -> DisassembledInst;
};

ARM64 encodes register operands in fixed 5-bit fields (supporting 32 registers). The rd, rn, rm extractors pull these fields from their standard positions.

Patch Validation

The most critical function is validating that patch points are legal:

auto X86_64Disassembler::validate_patches(const Stencil& s) const
    -> std::vector<std::string> {
  std::vector<std::string> errors;
  auto result = disassemble(s);

  for (const auto& patch : s.patches) {
    bool found = false;
    for (const auto& inst : result.instructions) {
      if (patch.offset >= inst.offset
          && patch.offset < inst.offset + inst.length) {
        found = true;

        // Validate patch type matches instruction type
        if (patch.type == PatchType::kImmediate64
            || patch.type == PatchType::kAddress64) {
          if (!inst.has_immediate) {
            errors.push_back(fmt::format(
                "Patch at offset {} is in '{}' which has no immediate",
                patch.offset, inst.mnemonic));
          }
        } else if (patch.type == PatchType::kRelativeJump) {
          if (inst.mnemonic != "jmp" && inst.mnemonic != "jnz"
              && inst.mnemonic != "jz") {
            errors.push_back(fmt::format(
                "Patch at offset {} (type=RelativeJump) is in '{}' "
                "which is not a jump",
                patch.offset, inst.mnemonic));
          }
        }
        break;
      }
    }

    if (!found && patch.offset < s.code.size()) {
      errors.push_back(fmt::format(
          "Patch at offset {} does not match any instruction", patch.offset));
    }
  }

  return errors;
}

This validation catches subtle bugs: a patch offset that's off by one byte would land in the middle of a multi-byte immediate, corrupting the instruction.

The CPU Emulator: Executing Without Hardware

Why Emulate?

Native execution is fast but inflexible:

• Cross-Platform Testing: Test ARM64 stencils on x86-64 development machines (or vice versa)
• Deterministic Debugging: Step through execution instruction by instruction
• Isolation: Execute stencils without affecting system state
• Instrumentation: Count instructions, trace register changes, profile hot paths

The emulator trades execution speed for observability and portability.

Architecture-Neutral IR

The heart of the emulator is an intermediate representation that abstracts away architectural differences. Both x86-64 and ARM64 translate to the same IR opcodes:

enum class EmulatorOp : uint8_t {
  // Integer Arithmetic
  kAddInt64,   // dst = src1 + src2
  kSubInt64,   // dst = src1 - src2
  kMulInt64,   // dst = src1 * src2
  kDivInt64,   // dst = src1 / src2 (signed)
  kModInt64,   // dst = src1 % src2 (signed)
  kNegInt64,   // dst = -src1
  kMsubInt64,  // dst = src2 - src1 * imm_reg (multiply-subtract)

  // Bitwise Operations
  kAndInt64,   // dst = src1 & src2
  kOrInt64,    // dst = src1 | src2
  kXorInt64,   // dst = src1 ^ src2
  kNotInt64,   // dst = ~src1
  kMovkInt64,  // dst = (dst & ~mask) | (imm << shift) - MOVK semantics

  // Floating-Point Arithmetic
  kAddDouble,  // dst = src1 + src2
  kSubDouble,  // dst = src1 - src2
  kMulDouble,  // dst = src1 * src2
  kDivDouble,  // dst = src1 / src2
  kNegDouble,  // dst = -src1
  kXorDouble,  // dst = bitwise_xor(src1, src2) - for XORPD

  // Comparison (sets condition flags)
  kCmpInt64,   // flags = compare(src1, src2)
  kCmpDouble,  // flags = compare(src1, src2)
  kTestInt64,  // flags = test(src1 & src2)

  // Conditional Set (reads flags, writes 0 or 1)
  kSetEq, kSetNe, kSetLt, kSetLe, kSetGt, kSetGe,
  kSetAbove, kSetAboveEq, kSetBelow, kSetBelowEq,
  kSetParity, kSetNoParity,

  // Data Movement
  kMovInt64, kMovDouble, kCselInt64,
  kLoadImm64, kLoadImmDouble,
  kZeroExtend8To64, kZeroExtend16To64, kZeroExtend32To64,
  kSignExtend8To64, kSignExtend16To64, kSignExtend32To64,

  // Type Conversions
  kInt64ToDouble,  // f[dst] = (double)r[src1]
  kDoubleToInt64,  // r[dst] = (int64_t)f[src1]

  // Memory Operations
  kLoadMem8, kLoadMem16, kLoadMem32, kLoadMem64, kLoadMemDouble,
  kStoreMem8, kStoreMem16, kStoreMem32, kStoreMem64, kStoreMemDouble,

  // Stack Operations
  kPush64, kPop64, kAllocStack, kDeallocStack,

  // Control Flow
  kBranch,           // pc = target (unconditional)
  kBranchIfZero,     // if (src1 == 0) pc = target
  kBranchIfNotZero,  // if (src1 != 0) pc = target
  kBranchIfEq, kBranchIfNe, kBranchIfLt, kBranchIfLe,
  kBranchIfGt, kBranchIfGe,

  // Function Calls
  kCallHelper,  // call helper function by ID
  kReturn,      // return from stencil

  kNop,
  kBreakpoint,
};

Each IR instruction is a compact struct:

struct EmulatorInst {
  EmulatorOp op;   // Operation type
  uint8_t dst;     // Destination register (0-31)
  uint8_t src1;    // First source register
  uint8_t src2;    // Second source register

  union {
    int64_t imm_i64;     // 64-bit immediate integer
    double imm_f64;      // 64-bit immediate double
    uint32_t target;     // Branch target (instruction index)
    uint32_t helper_id;  // Helper function identifier
    int32_t mem_offset;  // Memory access offset
  };

  uint32_t source_offset;  // Byte offset in original machine code
};

The Translation Pipeline

Translators convert architecture-specific machine code into the neutral IR:

The x86-64 translator handles the variable-length encoding complexity:

class X86_64Translator {
public:
  auto translate(const Stencil& stencil) -> EmulatorProgram;
  auto translate(std::span<const uint8_t> code, JITType result_type,
                 StencilOp stencil_op) -> EmulatorProgram;

private:
  struct Rex {
    bool present = false;
    bool w = false;  // 64-bit operand size
    bool r = false;  // ModRM.reg extension
    bool x = false;  // SIB.index extension
    bool b = false;  // ModRM.rm extension
  };

  struct ModRM {
    uint8_t mod;  // Addressing mode (0-3)
    uint8_t reg;  // Register operand / opcode extension
    uint8_t rm;   // Register/Memory operand
  };

  // Get emulator register index from x86-64 register encoding
  static auto gpr_to_emu_reg_(uint8_t reg, bool rex_ext) -> uint8_t;

  // Translate specific instruction types
  void emit_add_(const DecodedInst& inst, const uint8_t* code);
  void emit_mov_(const DecodedInst& inst, const uint8_t* code);
  void emit_cmp_(const DecodedInst& inst, const uint8_t* code);
  void emit_jcc_(uint8_t cc, const DecodedInst& inst, const uint8_t* code);

  // SSE instructions
  void emit_sse_arith_(uint8_t op, const DecodedInst& inst);
  void emit_cvtsi2sd_(const DecodedInst& inst, const uint8_t* code);

  // Resolve branch targets after first pass
  void resolve_branch_targets_();

  std::unordered_map<uint32_t, uint32_t> offset_to_index_;
  std::vector<std::pair<uint32_t, uint32_t>> pending_branches_;
};

The ARM64 translator leverages the regular instruction format:

class AArch64Translator {
public:
  auto translate(const Stencil& stencil) -> EmulatorProgram;

private:
  // Bit field extractors
  static auto rd_(uint32_t instr) -> uint8_t { return instr & 0x1f; }
  static auto rn_(uint32_t instr) -> uint8_t { return (instr >> 5) & 0x1f; }
  static auto rm_(uint32_t instr) -> uint8_t { return (instr >> 16) & 0x1f; }
  static auto sf_(uint32_t instr) -> bool { return (instr >> 31) & 1; }

  // Immediate extractors with sign extension
  static auto imm19_(uint32_t instr) -> int32_t {
    auto imm = static_cast<int32_t>((instr >> 5) & 0x7ffff);
    if (imm & 0x40000) {
      imm |= static_cast<int32_t>(0xfff80000);  // Sign extend
    }
    return imm * 4;  // Scale by 4 for branch offset
  }

  // Instruction category translators
  void translate_dp_reg_(uint32_t instr);   // Data processing (register)
  void translate_dp_imm_(uint32_t instr);   // Data processing (immediate)
  void translate_fp_(uint32_t instr);       // Floating-point
  void translate_ldst_(uint32_t instr);     // Load/store
  void translate_branch_(uint32_t instr);   // Branches
};

Emulator State: Registers, Flags, and Memory

The emulator maintains a complete CPU state:

// Register file holding both integer and floating-point registers
struct RegisterFile {
  std::array<int64_t, 32> r;  // Integer registers
  std::array<double, 32> f;   // Floating-point registers
  uint64_t sp;                // Stack pointer
  uint64_t pc;                // Program counter (instruction index)

  // ARM64 XZR (zero register) handling
  auto get_int(uint8_t reg, bool is_arm64 = false) const -> int64_t {
    if (is_arm64 && reg == 31) return 0;  // XZR always reads as 0
    return r[reg];
  }

  void set_int(uint8_t reg, int64_t value, bool is_arm64 = false) {
    if (is_arm64 && reg == 31) return;  // Writes to XZR are discarded
    r[reg] = value;
  }
};

// Condition flags (NZCV - compatible with both x86-64 and AArch64)
struct ConditionFlags {
  bool n;  // Negative: result is negative
  bool z;  // Zero: result is zero
  bool c;  // Carry: unsigned overflow/borrow
  bool v;  // oVerflow: signed overflow

  // Update flags after integer subtraction (CMP)
  void update_from_sub(int64_t src1, int64_t src2) {
    auto result = src1 - src2;
    n = (result < 0);
    z = (result == 0);
    // Carry for subtraction: set if no borrow (src1 >= src2 unsigned)
    c = (static_cast<uint64_t>(src1) >= static_cast<uint64_t>(src2));
    // Overflow: signs differ and result sign differs from src1
    v = (((src1 ^ src2) & (src1 ^ result)) < 0);
  }

  // IEEE 754 floating-point comparison flags
  void update_from_fcmp(double src1, double src2) {
    if (std::isnan(src1) || std::isnan(src2)) {
      n = false; z = false; c = true; v = true;  // Unordered
    } else if (src1 == src2) {
      n = false; z = true; c = true; v = false;
    } else if (src1 < src2) {
      n = true; z = false; c = false; v = false;
    } else {
      n = false; z = false; c = true; v = false;
    }
  }

  // Condition evaluation
  auto is_equal() const -> bool { return z; }
  auto is_less_than() const -> bool { return n != v; }
  auto is_greater_than() const -> bool { return !z && (n == v); }
  auto is_above() const -> bool { return c && !z; }  // Unsigned
};

Memory is emulated with a stack and optional literal pool:

class EmulatorMemory {
public:
  explicit EmulatorMemory(size_t stack_size = 64 * 1024);

  // Stack operations
  void push(int64_t value, uint64_t& sp);
  auto pop(uint64_t& sp) -> int64_t;
  void alloc(size_t bytes, uint64_t& sp);
  void dealloc(size_t bytes, uint64_t& sp);

  // Memory access
  auto load64(uint64_t addr) const -> int64_t;
  void store64(uint64_t addr, int64_t value);
  auto load_double(uint64_t addr) const -> double;
  void store_double(uint64_t addr, double value);

private:
  std::vector<uint8_t> stack_;
  std::vector<uint8_t> literal_pool_;
  uint64_t stack_base_;
};

The Execution Engine

The execution engine is a straightforward interpreter:

class ExecutionEngine {
public:
  auto execute(const EmulatorProgram& program, EmulatorState& state)
      -> ExecutionResult;
  void execute_instruction(const EmulatorInst& inst, EmulatorState& state);

private:
  // Integer arithmetic
  void exec_add_int64_(const EmulatorInst& inst, EmulatorState& state) {
    auto a = state.regs().get_int(inst.src1, state.is_arm64());
    auto b = state.regs().get_int(inst.src2, state.is_arm64());
    state.regs().set_int(inst.dst, a + b, state.is_arm64());
  }

  void exec_div_int64_(const EmulatorInst& inst, EmulatorState& state) {
    auto dividend = state.regs().get_int(inst.src1, state.is_arm64());
    auto divisor = state.regs().get_int(inst.src2, state.is_arm64());

    if (divisor == 0) {
      throw error::division_by_zero(state.regs().pc, create_snapshot_(state));
    }

    // Handle INT64_MIN / -1 overflow case
    if (dividend == std::numeric_limits<int64_t>::min() && divisor == -1) {
      state.regs().set_int(inst.dst, std::numeric_limits<int64_t>::min(),
                           state.is_arm64());
    } else {
      state.regs().set_int(inst.dst, dividend / divisor, state.is_arm64());
    }
  }

  // Comparison setting flags
  void exec_cmp_int64_(const EmulatorInst& inst, EmulatorState& state) {
    auto a = state.regs().get_int(inst.src1, state.is_arm64());
    auto b = state.regs().get_int(inst.src2, state.is_arm64());
    state.flags().update_from_sub(a, b);
  }

  // Conditional branching
  void exec_branch_if_lt_(const EmulatorInst& inst, EmulatorState& state) {
    if (state.flags().is_less_than()) {
      state.regs().pc = inst.target;
      ++stats_.branches_taken;
    } else {
      ++state.regs().pc;
      ++stats_.branches_not_taken;
    }
  }
};

The main execution loop:

auto ExecutionEngine::execute(const EmulatorProgram& program,
                              EmulatorState& state) -> ExecutionResult {
  state.regs().pc = 0;
  state.set_returned(false);

  while (state.regs().pc < program.instructions.size()
         && !state.has_returned()) {
    // Check instruction limit
    if (config_.max_instructions > 0
        && stats_.instructions_executed >= config_.max_instructions) {
      throw error::max_instructions_reached(config_.max_instructions,
                                            state.regs().pc);
    }

    const auto& inst = program.instructions[state.regs().pc];
    execute_instruction(inst, state);
    ++stats_.instructions_executed;

    // Advance PC (unless branch already modified it)
    if (!is_control_flow(inst.op)) {
      ++state.regs().pc;
    }
  }

  return ExecutionResult::kSuccess;
}

The Debugger: Step Through JIT Code

The debugger provides fine-grained control over emulator execution:

class Debugger {
public:
  // Breakpoint Management
  auto add_breakpoint(uint32_t instruction_index) -> uint32_t;
  void remove_breakpoint(uint32_t instruction_index);
  auto has_breakpoint(uint32_t instruction_index) const -> bool;

  // Execution Control
  void attach(ExecutionEngine* engine, const EmulatorProgram* program,
              EmulatorState* state);
  auto run() -> DebugState;      // Run until breakpoint
  auto step() -> DebugState;     // Single step
  auto continue_execution() -> DebugState;

  // State Inspection
  auto get_int_register(uint8_t reg) const -> std::optional<int64_t>;
  auto get_fp_register(uint8_t reg) const -> std::optional<double>;
  auto get_flags() const -> std::optional<ConditionFlags>;
  auto get_stack_pointer() const -> std::optional<uint64_t>;

  // Execution History
  auto history() const -> const std::deque<ExecutionRecord>&;
  void set_history_enabled(bool enabled);

private:
  ExecutionEngine* engine_;
  const EmulatorProgram* program_;
  EmulatorState* emulator_state_;
  std::vector<Breakpoint> breakpoints_;
  std::deque<ExecutionRecord> history_;
};

Execution history records register changes for each instruction:

struct ExecutionRecord {
  uint32_t instruction_index;
  EmulatorOp op;
  uint32_t source_offset;
  bool is_fp;

  // Integer register values
  int64_t dst_before, src1_before, src2_before, dst_after;

  // FP register values
  double fp_dst_before, fp_src1_before, fp_src2_before, fp_dst_after;
};

This enables powerful debugging workflows: set a breakpoint, run to it, then step through while watching register values change.

The Helper Dispatcher: Bridging to Document API

JIT stencils need to access document fields, but we can't execute real pointer dereferences in emulation. The HelperDispatcher provides document API functions:

enum class HelperId : uint32_t {
  // Field access
  kGetInt64Field,
  kGetDoubleField,
  kGetBoolField,
  kGetStringField,
  kIsFieldNull,

  // Cached field access
  kGetInt64FieldCached,
  kGetDoubleFieldCached,

  // String operations
  kStringEq, kStringNe, kStringLt, kStringContains,
  kStringStartsWith, kStringEndsWith,

  // Array operations
  kArrayGetInt64, kArrayContainsInt64, kGetArrayLength,
};

class HelperDispatcher {
public:
  void dispatch(HelperId id, EmulatorState& state);

private:
  void dispatch_get_int64_field_(EmulatorState& state) {
    // Extract document pointer and field name from calling convention
    auto doc_ptr = reinterpret_cast<const Document*>(
        state.is_arm64()
            ? state.regs().r[arm64_reg::kArg0]
            : state.regs().r[x86_reg::kArg0]);
    auto field_name_ptr = reinterpret_cast<const char*>(
        state.is_arm64()
            ? state.regs().r[arm64_reg::kArg1]
            : state.regs().r[x86_reg::kArg1]);

    // Actually call the document API
    auto result = doc_ptr->get_int64(field_name_ptr);

    // Store result in return register
    if (state.is_arm64()) {
      state.regs().r[arm64_reg::kReturnInt] = result;
    } else {
      state.regs().r[x86_reg::kReturnInt] = result;
    }
  }
};

This allows stencils that call helper functions to execute correctly in emulation while still accessing real document data.

The High-Level Interface

The StencilEmulator ties everything together:

class StencilEmulator {
public:
  explicit StencilEmulator(const EmulatorConfig& config = {});

  // Execute a stencil with a document
  auto execute(const Stencil& stencil, const Document& doc) -> TypedValue;

  // Execute a stencil (pure arithmetic)
  auto execute(const Stencil& stencil) -> TypedValue;

  // Debugging interface
  auto debugger() -> Debugger& { return debugger_; }
  auto prepare(const Stencil& stencil) -> const EmulatorProgram&;
  auto step() -> bool;
  auto run_to_completion() -> TypedValue;

  // Architecture detection
  static auto detect_architecture(const Stencil& stencil) -> ArchType;
  static auto is_x86_64(const Stencil& stencil) -> bool;
  static auto is_aarch64(const Stencil& stencil) -> bool;

  // Translation cache
  void clear_cache();
  auto cache_hits() const -> uint64_t;
  auto cache_misses() const -> uint64_t;

private:
  auto translate_(const Stencil& stencil) -> const EmulatorProgram&;

  EmulatorConfig config_;
  ExecutionEngine engine_;
  EmulatorState state_;
  Debugger debugger_;
  HelperDispatcher dispatcher_;
  std::unordered_map<uint64_t, EmulatorProgram> cache_;
};

Architecture detection looks at the first few bytes to identify the instruction set:

auto StencilEmulator::detect_architecture(const Stencil& stencil) -> ArchType {
  if (stencil.code.size() < 4) return ArchType::kUnknown;

  // ARM64: fixed 32-bit instructions, often start with specific patterns
  // x86-64: variable length, common patterns include REX prefixes (0x40-0x4F)

  // Heuristic: ARM64 instructions have distinctive bit patterns
  uint32_t first_word = stencil.code[0] | (stencil.code[1] << 8)
                      | (stencil.code[2] << 16) | (stencil.code[3] << 24);

  // Check for common ARM64 patterns
  if ((first_word & 0x9F000000) == 0x91000000  // ADD immediate
      || (first_word & 0xFF000000) == 0xD6000000  // BR/BLR/RET
      || (first_word & 0x7F800000) == 0x2A000000) { // ORR shifted register
    return ArchType::kAArch64;
  }

  return ArchType::kX86_64;
}

Usage Example

Here's how you might use the emulator for debugging:

auto stencil = get_add_int64_stencil();
auto emulator = StencilEmulator {};

// Enable debugging
auto& dbg = emulator.debugger();
dbg.set_history_enabled(true);

// Prepare the stencil (translate to IR)
auto& program = emulator.prepare(stencil);

// Set a breakpoint at instruction 3
dbg.add_breakpoint(3);

// Attach debugger
dbg.attach(&emulator.engine(), &program, &emulator.state());

// Run until breakpoint
auto result = dbg.run();
if (result == DebugState::kBreakpoint) {
  // Inspect state
  std::cout << "Stopped at instruction " << dbg.current_instruction() << "\n";
  std::cout << "Registers:\n" << dbg.format_registers() << "\n";

  // Step through remaining instructions
  while (dbg.step() != DebugState::kFinished) {
    std::cout << dbg.format_current_instruction() << "\n";
  }
}

// Print execution history
std::cout << dbg.format_history(20) << "\n";

Performance Characteristics

The emulator prioritizes observability over speed:

The 50-100x slowdown is acceptable for testing and debugging. For benchmarking JIT code quality, we use native execution.

Conclusion

Building a JIT compiler requires more than just code generation. The disassembler validates that generated code is correct---that patch points land at instruction boundaries, that immediates are in the right positions. The emulator enables cross-platform development, deterministic debugging, and fine-grained performance analysis.

These tools transformed our JIT development workflow:

• Stencil Authors can validate patches without running the code
• Debuggers can step through compiled expressions instruction by instruction
• CI Systems can run the full test suite on any architecture
• Performance Engineers can get exact instruction counts without sampling overhead

The investment in tooling pays for itself many times over. JIT compilation is inherently error-prone---invisible code, platform-specific behavior, subtle encoding bugs. Good tools make the invisible visible.

References

1. Intel 64 and IA-32 Architectures Software Developer's Manual
2. ARM Architecture Reference Manual for A-profile architecture
3. Xu, H., & Kjolstad, F. (2021). Copy-and-Patch Compilation: A fast compilation algorithm for high-level languages and bytecode. OOPSLA.
4. QEMU: A Fast and Portable Dynamic Translator. Bellard, F. (2005). USENIX Annual Technical Conference.
